    Product Details:

    Place of Origin: China
    Brand Name: OLYMSPAN
    Certification: CE,ASME,GB150
    Model Number: Φ2.5×31m
    Type: AAC Autoclave

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: US $ 18,000 - 120,000 / Set
    Packaging Details: Nude
    Delivery Time: 60days(according to order quantity)
    Payment Terms: T/T,L/C,EXW
    Supply Ability: 45 Sets Per Month
    Contact Now
    Detailed Product Description
    Plate Thickness: 20mm Light Rail: 15kg/m
    Working Temperature: 201 Celsius Degree Hydraulic Test: 2.1 Mpa
    Warranty: 1 Year

    Industrial Insulated AAC Autoclave With Autoclaved Aerated Concrete Block  ASME standard





    Quick Details:



    Heating medium: saturated steam                      Rail distance & height: 800×200(General) (can be design according to buyer)

    Light rail: 15kg/m (China-standard)                     Admission direction: both middle-sides inlet

    Door opening form: double upside opening      Inlet pipe diameter:DN100

    Plate thickness: 20mm                                          Designed temperature: 204 Celsius degree

    Designed pressure: 1.6 Mpa                                Working temperature: 201 Celsius degree

    Working pressure: 1.5 Mpa                                   Hydraulic test: 2.1 Mpa

    Safety valve working pressure: 1.58Mpa            Working medium: saturated steam

    Heating method: High temperature steam        Main pressure parts: Q345R(GB713), 16MnⅡ (NB/T47008)

    Designed service life: 20 Years                           Weight: 58 Tons

    The enclosure dimensions are 33m×3m×2.9m . (nude package)

    Raw Material: sand lime brick, cement, flyash brick, slag brick, aerated concrete block, etc.





    After-sales service



    1. Provide reasonable suggestions for production line of autoclave of users to yield the gratest efficiency of equipments.
    2. Freely direct position, installation, debugging, and on-site training to use normally, and direct users to use autoclave safely, high efficiently, and conveniently.
    3. Review clients for usage of autoclave.
    4. Provide quick-wear parts and spare parts .



    What is AAC ?

    1. Aerated Autoclaved concrete block (light block ) is the light and porous building material. It has light ,keeping temperature , Environmental protection,can't burn and other advantages.it has a wide prospect of market.it is the main building material in the future. it can be made into many kinds of bricks(for example:600×200×100,80×80×180,240×115×53,600×200×125),they could be used industry building and common building.they are more and more popular in the world.in the future,they will replace the Clay brick completely.

    2. Areated concrete common conception.Common concrete density is usually 1600-2400kg/m3,but areated concrete are 500kg/m3,600kg/m3,700kg/m3.It has not the big grain,main use silicon material (for example:flyash,sand,stone dust and others ),through making the material small for example sand,they can be used directly if has enough degree of small (for example fly ash.Mixing calcium material lime, cement water to a special slop,then add the aluminum dust and the additive.Make the aluminum dust and the special slop have a Chemical reflect.then produce Hydrogen to make the concrete slop to expanding or swell,foam.Next,put them into the curing room to concreting cutting steaming curing,last,there will bacome the light brick,the porous rate is 70-80%.



    AAC Autoclave / Sand Lime Brick /Aerated Autoclaved Concrete Block / Flyash Brick



    Feature of AAC:

    1. Thermal Insulation
    It has highest thermal rating in the industry….R30! Thus provides well insulated interiors, keeping out warm air in summer and cold air in winters.AAC reduces Air conditioning cost by 30%.
    2. Sound proof
    AAC wall has an excellent sound Transmission class (STC) ,rating of 44. Result: Virtually Soundproof  Interiors!
    3. Earthquake Resistant
    Earthquake forces on structure are proportional to the weight of the building, hence AAC shows excellent resistant to earthquake forces. Regions of high seismic activity like Japan exclusively use AAC. It has been proven to withstand wind loads of category 5 tropical storms.
    4. Floor Space Area
    Use of thinner blocks (6" instead of 9" exterior walls) because of its excellent water barrier & insulation properties leads to an increase in floor space area between 3-5%.
    5. Cost saving
    Being lightweight AAC drastically reduces the dead weight of building, resulting into reduction in steel (up to 27%) and cement (up to 20%) structural cost saving.Being 8 times the size of a clay brick, AAC wall construction involves 1/3 the joints, thus an overall mortar saving up to 66%.
    Its automatic manufacturing process gives AAC an exceptional dimensional accuracy & smooth surfaces, eliminating need of three-coat plaster walls and allows for a final 6 mm skim coat (putty/POP).
    6. Fire Resistant
    Best in class fire rating of 4 hours. The melting point of AAC is over 1600 ºc, more than twice the typical temperature in a building fire of 650 ºc.


    AAC land and workshop require:

    50000m3 to100000m3,workshop is 2000m2,the land is 8000m2.
    150000m3,workshop is 2500m2,the land is 10000m2.
    200000-300000 m3,workshop is 3000m2,the land is 15000m2.
    Above please refer to ,the bigger the better.
            AAC Autoclave / Sand Lime Brick /Aerated Autoclaved Concrete Block / Flyash Brick        AAC Autoclave / Sand Lime Brick /Aerated Autoclaved Concrete Block / Flyash Brick
            AAC Autoclave / Sand Lime Brick /Aerated Autoclaved Concrete Block / Flyash Brick        AAC Autoclave / Sand Lime Brick /Aerated Autoclaved Concrete Block / Flyash Brick
            AAC Autoclave / Sand Lime Brick /Aerated Autoclaved Concrete Block / Flyash Brick        AAC Autoclave / Sand Lime Brick /Aerated Autoclaved Concrete Block / Flyash Brick
            AAC Autoclave / Sand Lime Brick /Aerated Autoclaved Concrete Block / Flyash Brick        AAC Autoclave / Sand Lime Brick /Aerated Autoclaved Concrete Block / Flyash Brick


    Product Description:

    Autoclave is key equipment which has a widely application in building material factory to autoclaved cure different kinds of building materials. It is also used in areas of chemical, textile, wood, Glass, Brick, metallurgy, Rubber, military industry. Convenient operation, security and reliable are its advantages.

    Autoclave belongs to pressure vessel which has explosion risk. According to the supervision regulation on safety technology for pressure vessel on divide standard of pressure vessel, the product is part of first and second class pressure vessel. Before putting into operation, the end-user must register in the local boiler and pressure vessel safety supervision organization and acquire the operation permit, at the same time it must accept supervision and inspection.



    Advantages of Autoclave of Olymspan



    1. Patents we possess at present:

    a) Autoclave of hydraulic automatic opening-door device (ZL 2011 2 0025592.4)
    b) The pressure drainage device of autoclave (ZL 2011 2 0025595.8)
    c) Posses autoclave of automatic door operator (ZL 2011 2 0025674.9)
    d) Worktable of cutting kettle tooth (ZL 2011 2 0025738.5)
    e) Electrical safety interlock device of autoclave (ZL 2011 2 0026871.2)

    2. Material:
    a) Q345R-GB713 of Hanggang in Hebei.
    b) 16MnIIlevel of making flange forging
    c)  φ133×25 tube to make DN100 and the material is 20-GB9948.

    3. Process:
    a) After welding kettle door, it must proceed annealing heat treatment.
    b) Polish toothed cutter of flange of autoclave body, and carry out magnetic particle testing.
    c) Use double scale container board, and ensure the longitudinal joint of each section.
    d) Carry out the physical and chemical test (stretch, impact), ensure its strength.
    e) Welds are 100% X-ray detection, then carry out hydraulic test of 2.1MPa after passing. The whole process is complete inspected by CSEI factory inspection, and leave factory after stamp and signature .

    4. Security Measures:(Triple Security)
    a).Hand speed reducer installs mechanical interlocking, and we don't move when there's pressure in kettle.
    b).Equip with manual limited safety interlocking device, stuck kettle manually, and when it opens , then we can open the door.
    c).Equip with electric limited safety interlocking device,use cooperatively with manual limit, and connect with electric cabinet, rotating electrical ark with pressure and sound-light alarm.



    Specifications:





    Item

    Type

    Φ1.65m*L

    Φ2m*L

    Φ2.5m*L

    Φ2.68m*L

    Φ2.85m*L

    Φ3m*L

    Φ3.2m*L

    Inner diameter

    Ø 1.6m

    Ø 2m

    Ø 2.5m

    Ø 2.68m

    Ø 2.85m

    Ø 3m

    Ø 3.2m

    Length

    L

    L

    L

    L

    L

    L

    L

    Designed pressure

    1.6Mpa

    1.6Mpa

    1.6Mpa

    1.6Mpa

    1.6Mpa

    1.6Mpa

    1.6Mpa

    Designed temperature



    204℃



    204℃



    204℃



    204℃



    204℃



    204℃



    204℃

    Max operation pressure

    1.5Mpa

    1.5Mpa

    1.5Mpa

    1.5Mpa

    1.5Mpa

    1.5Mpa

    1.5Mpa

    Max operation temperature

    201℃

    201℃

    201℃

    201℃

    201℃

    201℃

    201℃

    Medium

    Saturated Steam

    Rail distance / height

    600mm/

    150mm

    600mm/

    150mm

    800mm/

    200mm

    800mm/

    250mm

    963mm/

    280mm

    1220mm/320mm

    1220mm/

    320mm

    Corrosion allowance

    2mm

    2mm

    2mm

    2mm

    2mm

    2mm

    2mm
