Wood Plastic Door / Floor Sanding Machine Plastic Auxiliary Equipment

Wood Plastic Door / Floor Sanding Machine Plastic Auxiliary Equipment

    • Wood Plastic Door / Floor Sanding Machine Plastic Auxiliary Equipment
    • Wood Plastic Door / Floor Sanding Machine Plastic Auxiliary Equipment
    • Wood Plastic Door / Floor Sanding Machine Plastic Auxiliary Equipment
  • Wood Plastic Door / Floor Sanding Machine Plastic Auxiliary Equipment

    Product Details:

    Place of Origin: Qingdao Shandong China
    Brand Name: Weier
    Certification: CE SGS
    Model Number: WEIER

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: 1500-20000 USD
    Packaging Details: ACCORDING TO CUSTOMER NEEDS
    Delivery Time: 35 days after contract confirmed
    Payment Terms: TT L/C
    Supply Ability: 20 DAYS
    Contact Now
    Detailed Product Description

    Wood Plastic Door / Floor Sanding Machine Plastic Auxiliary Equipment



    Quick Detail:



    ) two head
    2) Heavy duty
    3) Single surface
    4) max working width 600 or 1300mm
    5) CE certificate and ISO9001





    Description:


    Company information:

    Qingdao Weier Plastic Machinery Co., LTD is a professional manufacturer who is devoted

    to macromolecule science and plastic machinery and equipment,is the director member of WPCC(Plastic &Wood Production Council of Chinese Plastic Community), now we are Plastic Engineering Technology Research Institute of Qingdao Science andTechnology

    University Test and Industrialization center.

    We cooperated with many domestic universities to develop special plastic machines to

    meet domestic and foreign customer’s requirement and have a strong association with

    many macromolecule and chemical majors of many universities. At the same time we

    bring in and absorb advanced processing engineering of foreign plastic machines to

    realize chain service of technics and machines.


    Sanding machine can be used to polish various board by giving thiokness and it suits to polish solid wood door, veneer board, shaving board, cement board fibre board .middle-density fibrous board frame etc This machine consists of frame feeding device lifting device, electrical device and automatic control device This machine has two thickness rollers and a sanding pad, sanding pad can work alone Board processing surface more meticulous, high efficiency




    Applications:



     This model is especially suitable for artificial wooden board, multi-layer board,chipboard, finger-joint board processing.





    Specifications:



    model

    SFE130R-RP

    SFE130RP-P

    Width of sanded panel

    40-1300mm

    40-1300mm

    Thickness of sanded panel

    3-120mm

    3-170mm

    Speed of abrasive belt on 1st unit

    18m/s

    18m/s

    Speed of abrasive belt on 2nd unit

    12m/s

    12m/s

    Feed speed

    6-30m/min

    6-30m/min

    Size of abrasive belt

    1330*2500mm

    1330*2500mm

    Total power

    56.62/63.62KW

    39.82KW

    Power of abrasive belt on 1st unit

    30Kw/37Kw

    22Kw

    Power of abrasive belt on 2nd unit

    22Kw

    15Kw

    Conveyer motor power

    4Kw

    2.2Kw

    Lifting motor power

    0.25Kw

    0.25Kw

    Brush motor power

    0.37Kw

    0.37Kw

    Pressure

    0.55Mpa

    0.55Mpa

    Compressed air consumption

    0.2m³/min

    0.2m³/min

    Compressed air volume

    >8000m³/h

    >8000m³/h

    Speed required for cleaning equipment

    25-30m/s

    25-30m/s

    Weight

    3200Kg

    3000Kg

    Overall dimension

    2600*2020*2130mm

    2525*2020*2100mm





    Competitive Advantage:



    The rotate speed and height of sanding rollers and sanding discs, the feed speed of convey belt are shown on the computer control panel, all the speed can be adjusted.
