Multilayer PP PS HIPS Plastic Sheet Extrusion Machine for stationery sheet

Multilayer PP PS HIPS Plastic Sheet Extrusion Machine for stationery sheet

  • Multilayer PP PS HIPS Plastic Sheet Extrusion Machine for stationery sheet
Multilayer PP PS HIPS Plastic Sheet Extrusion Machine for stationery sheet
Product Details:
Place of Origin: Ruian
Brand Name: Shelly
Certification: CE
Model Number: SL
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: export wooden case
Contact Now
Detailed Product Description
Width: 100-1200mm Speed: 10-200 M/min
Controlled: Computer Material: Pe Pp Pvc Hdpe Ldpe Pet
Size: 100-1500mm Surface Hardness: 60-70HR
Chrome Thickness: 0.035-0.045mm Polishing: Lips And Surface Of Flowing: 0.02-0.03(μm), Other Surfaces: 0.03-0.04(μm).
High Light:

Plastic Sheet Extrusion Line

,

pet sheet extrusion line

PLC Controlled High Speed Good Quality Plastic Sheet Extrusion Machine Good Quality







100-65B Plastic Sheet Extrusion Line:



1, Die head are made of high quality corrasion resistive alloy steel, runner plated chrome, thickness is 0.02-0.03mm, rough is ra0.05μm;
2, Barrel and screw with high-precision, long life and corrosion resistive;
3, Speed decreasing box with hardness gear;
4, Temperature controlled by pid in high precision;
5, Cooling water inside of polish roller is screw model structure, the temperature of surface roller is equality, treatment by polish with rough ra0.05μm and HV≥850;
6, Tension of rewinder controlled by magnetic dutch with stablity;
It is used for produce PP, PS ,PE etc plastic sheet which can be widely used for plastic forming sheet, stationery sheet and adhesive tape with corrosion resistance etc,as packing plastic containers, trays, cups, bowls and plates.





Maximum outpu :200kg/h
Diameter of screw:100mm
Thickness of die mouth:0-3mm
Diameter of roller:Φ400mm
Adjust distance of roller:0-50mm
Diameter ratio:30:1
Width of die nozzle:850mm
Face length of roller :1000mm
Number of roller:3
Motor power of extrude:75kw
Heating power of drum :22kw
Heating power of die head :15kw
Heating power of screen changer:5kw
Motor power of calendar:2.2kw×3
Motor power of rewinder:2.2kw
Air consumption :0.6Mpa
Water consumption :20m³/h
Air pressure:0.1m³/h
Sheet thickness range:0.3-2mm
Width Maximum::700mm
Gear Pump:100cc/hr





100B Plastic Sheet Extrusion Line is a combination of extruder,calender,rewinder and electric control box etc.The drum,screw,screen changer and die head are made of high quality alloyed steel(38CrMoAIA) with high hardness,strong corrcsion resistance and long operating life after nitrogen trestment.The head is adopted hanger-type branch pipe decreasing-style construction,so the flow passage is convenient for solution to flow without stagnation and cooling inside roll and bring a perfct effect.The temperature of die head,mesh changer and the drum separately controlled.All drive systerm runs synchronously.



It is used for produce various plastic sheet of PP,PS,HIPS,and PET etc.which can be widely used for produce plastic formed sheet,stationery sheet,and adhesive tape with corrosion resistance etc.



Multilayer PP PS HIPS Plastic Sheet Extrusion Machine for stationery sheet 0
