Electric Barrel Beverage Automatic Water Filling Machine For Mineral Water

Electric Barrel Beverage Automatic Water Filling Machine For Mineral Water

    • Electric Barrel Beverage Automatic Water Filling Machine For Mineral Water
    • Electric Barrel Beverage Automatic Water Filling Machine For Mineral Water
    • Electric Barrel Beverage Automatic Water Filling Machine For Mineral Water
    • Electric Barrel Beverage Automatic Water Filling Machine For Mineral Water
  • Electric Barrel Beverage Automatic Water Filling Machine For Mineral Water

    Product Details:

    Place of Origin: ZHANGJIAGANG CHINA
    Brand Name: BJM
    Certification: ISO9001, CE
    Model Number: CGF50-50-15

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: negotiation
    Packaging Details: Seaworthy wooden case
    Delivery Time: 30 days after bottle sample received
    Payment Terms: T/T, L/C, Western Union
    Supply Ability: 24,000 bottles per hour (500ml)
    Contact Now
    Detailed Product Description
    Warranty: One Year Filling Head: 50 Pcs
    Capping Head: 15 Pcs Bottle Volume: 200ml To 1500ml/2L To 10L
    Bottle Type: PET/Plastic/PE/PP Bottle Bottle Shape: Round, Square, Rectangular, Irregular
    Washing Head: 50 Pcs Total Power: 9.6KW
    Overall Size: 5450*3210*2400mm(L*W*H) Cap Type: Plastic Screw Cap/Pressing Cap/Sport Cap
    Spare Parts: One Year Free Spare Parts

    Mineral Water Production Plant/Automatic Water Filling Machine for PET/Glass bottle





    Quick Detail:



    • Warranty: 1 year and free spare parts in one year
    • Engineers available to service machinery overseas
    • Full line including: Bottle Sorter, Rinser-Filler-Capper 3 in 1 machine, Lamp Checker, Labeling Machine, Film Shrink Machine/Carton Packing Machine
    • We supply 3,000 to 24,000 bottles/hour
    • Application: Pure water/Mineral water/Drinking water/Non-carbonated water/Beverage/Codiment etc
    • Capacity: 24,000 bottles per hour
    • Bottle Type: 200ml to 1.5L/2L to 10L
    • Cap Type: Screw cap, Pressing Cap, Sport cap
    • Bottle Type: PET/PP/PE/HDPE Plastic Bottle
    • Model: CGF50-50-15 3 in 1 Monoblock
    • Place of Origin: Zhangjiagang city, China near Shanghai
    • Brand: BJM
    • Rinser Head: 50 pcs
    • Filler Head: 50 pcs
    • Capper Head: 15 pcs
    • Bottle Shape: Round/Square/Rectangular/Irregular



    Specifications:



    Application

    Pure water/Mineral water/Drinking water/Non-carbonated water/Beverage/Codiment etc

    Suitable bottle Type

    PET bottle with size 200ml to 1500ml/2L to 10L

    Bottle Height

    Bottle height. Φ160—φ340mm

    Bottle Diameter

    Bottle dia.φ50-φ90mm

    Suitable cap type

    Plastic Screw Cap/Pressing Cap/Sport Cap

    Supply Capacity

    24,000 bottles per hour(500ml bottle)

    Filling Type

    Mico Low Negative filling type

    Filling Temperature

    Ambient/Room Temperature

    Voltage

    220/380V(Custom made)

    Power 50HZ/60HZ(Custom made)

    Automatic Grade

    Fully Automatic

    Driven Type

    Electric

    Material:

    High quality SUS304 stainless steel

    After-sales Service  Engineers available to service machinery overseas





    Description and feature:



    Automatic Rinser





    1. Professional cleaning machine for empty plastic bottle or glass bottles.
    2. Fixed structure, impeccable controlling system and easily for operating and maintain.
    3. Reliable cleaning theory and spraying method to rinse the inside and outside of the bottles.
    4. When change the bottles, only need to change the star wheel and guide plate, no other machine accessory need to change; this machine is suitable for rinsing PET bottles and glass bottle, can be used for large and middle-size enterprise, not only for the whole filling line, but also for the separate working;



    Automatic Filler



    1. Filling valve uses German advanced technology, even with running speed 24,000 bottles per hour, our machine can fill stably and exactly;
    2. All filling accessory have been well polished, and have nice appearance , fast filling speed, without any leakage;
    3. Themachine is equipped with anti-reverse rotation unidirectional clutch device. When it overload, the clutch will slip to stop the machine, so that the machine can work normally.
    4. The machine can fill the PET bottle which can not be filled by low vacuum filling machine.




    Automatic Capper



    1. The capping machine is suitable for plastic screw cap , aluminum screw cap, theft deterrent cap, etc which is mainly used in the PET bottled no-gas drinking ;
    2. The capping machine has the stable transmission system, great sealing performance, easy operation, convenient maintance character.





    Main Parts supplier



    1. Main motor                                           Siemens
    2. Liquid level sensor                               France
    3. Pump                                                    South Pump(China Famous Brand)
    4. Touch screen                                       Taiwan
    5. PLC                                                       Mitsubishi
    6. Inverter                                                  Mitsubishi
    7. Photoelectric switch                               Omron
    8. Contactor, Circuit breaker                     Snyder France
    9. Bearing                                                  NSK Japan
    10. Seal ring                                                U.S
    11. Material contact valve, tank, pipe          SUS304/316L

    All Parts we can custom made for requirement for each customer, like Grundfos Pumps, Sew Motor, Festo Electric Appliance, etc.



    Competitive Advantage:



    • Experienced in this field more than 20 years
    • Free technical support&consultation
    • Professional & fast after service team
    • Warranty: 12 months
    • Free spare parts for one year
    • Delivery time: in time

    Electric Barrel Beverage Automatic Water Filling Machine For Mineral Water

    When you send inquiry, please also included the capacity and bottle volume you need to work on the machine, it is easy and accurate for us to recommend proper machine model.





    Benjamin Machinery pays great attention to technology, such as beer processing and filling technology, high-viscosity filling technology, glass bottle water filling technology. And we will try our best to satisfy your requirement, your message will be highly appreciated. Welcome to Benjamin Machinery.
