H beam Production Line Shot Blasting Machines for Rust Removing And Polishing of Surface

H beam Production Line Shot Blasting Machines for Rust Removing And Polishing of Surface

    • H beam Production Line Shot Blasting Machines for Rust Removing And Polishing of Surface
    • H beam Production Line Shot Blasting Machines for Rust Removing And Polishing of Surface
    • H beam Production Line Shot Blasting Machines for Rust Removing And Polishing of Surface
    • H beam Production Line Shot Blasting Machines for Rust Removing And Polishing of Surface
  • H beam Production Line Shot Blasting Machines for Rust Removing And Polishing of Surface

    Product Details:

    Place of Origin: China
    Brand Name: H-WELDING
    Certification: CE
    Model Number: HP1018

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set
    Price: negotiation
    Packaging Details: Mainframe naked in container, electrical control box in plywood cases (Non fumigation) then in container.
    Delivery Time: 15 working days after received your payment
    Payment Terms: 30% T/T as advance payment when sign the contract, 70% T/T as balance payment before delivery or 100% irrevocable LC at sight
    Supply Ability: 30sets per month
    Contact Now
    Detailed Product Description
    Product Name: H Beam Shot Blasting Machine Application: Steel Plate Polish
    Straightening Type: Mechanical Conveyor: Roller Type
    Available Flange Thickness: Less Then 1000mm Linkage Control: Available
    Input Conveyor: 12m Output Conveyor: 12m

    H Beam Shot Blasting Machine In H beam Production Line for Rust Removing And Polishing On The Surface



    Specifications:



    Model

    HP6012

    HP8016

    HP1018

    Work-piece size

    section(width*heigh )

    600*1200mm

    800*1600mm

    1000*1800mm

    Length

    3000-12000mm

    3000-12000mm

    3000-12000mm

    Quality standard

    Surface cleanness

    A-B Sa2-Sa2 1/2

    A-B Sa2-Sa2 1/2

    A-B Sa2-Sa2 1/2

    Surface roughness

    15-50H beam Production Line Shot Blasting Machines for Rust Removing And Polishing of Surface

    15-50H beam Production Line Shot Blasting Machines for Rust Removing And Polishing of Surface

    15-50H beam Production Line Shot Blasting Machines for Rust Removing And Polishing of Surface

    Shot head

    Number

    4

    8

    8

    Shots volume

    4*250kg/min

    8*200kg/min

    8*250kg/min

    Power

    4*15kw

    8*11kw

    8*15kw

    Input/output conveyor

    Loading

    1000kg/m

    1000kg/m

    1000kg/m

    Transport speed

    0.4-4m/min

    0.4-4m/min

    0.4-4m/min

    Dust collect volume

    15300m3/h

    15300m3/h

    20400m3/h

    Shots recovery volume

    70t/h

    96t/h

    120t/h

    Power

    106.7kw

    137kw

    183.9kw



    Description:



    • Advanced SH-model full-curtain type separator is the product developed successfully by us on the basis of introducing advanced international technique.



    Applications:



    • Of which all the performance indexes have reached abroad level of similar products. On the basis of winnow principle, the separator can separate dust, scrap of oxide-layer, broken shots, and foreign particles from useful shots.



    Competitive Advantage:



    • The    international-advanced    filter-barrel    type dust-collector    has    profits    as    high dust-collecting efficiency, low running resistance, small volume, light weight and easy maintenance.

    H beam Production Line Shot Blasting Machines for Rust Removing And Polishing of Surface

    H beam Production Line Shot Blasting Machines for Rust Removing And Polishing of Surface
