PVC plastic bottle recycle machine / PET recycling machine high speed

PVC plastic bottle recycle machine / PET recycling machine high speed

    • PVC plastic bottle recycle machine / PET recycling machine high speed
    • PVC plastic bottle recycle machine / PET recycling machine high speed
    • PVC plastic bottle recycle machine / PET recycling machine high speed
    • PVC plastic bottle recycle machine / PET recycling machine high speed
  • PVC plastic bottle recycle machine / PET recycling machine high speed

    Product Details:

    Place of Origin: CHINA
    Brand Name: FLAME
    Certification: ISO9001:2000,CE
    Model Number: 300Kg-3000Kg Bottles Recycling Cleaning Production Line

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: USD68,000~200,000/set
    Packaging Details: Standard Export Packing
    Delivery Time: 40 working days
    Payment Terms: T/T
    Supply Ability: 5 sets/40 days
    Contact Now
    Detailed Product Description
    Material: Stainless Steel Output: 300-2000kg/h
    Electric Appliance: Siemens

    PVC plastic bottle recycle machine / PET recycling machine high speed





    1. Introduction of Product

    300Kg-3000KgPP/P/PVC/PET Waste Barrels And Bottles Recycling Cleaning Production Line.

    PET mineral water bottles, cola bottle full automatic crushing washing dewatering and drying production line is the ideal equipment to waste mineral water bottle, cola bottle, PET bottle sorting, label removing, crushing, washing, dewatering and drying machine. This machine through a trial research by R&D to develop this new generation high efficiency, water-saving equipment.

    The quality of flakes used our equipment is similar to the new material can connect POY filament, staple, bottle perform, PET packing belt, sheet material directly etc. The equipment can wash PP, PE, ABS, PVC sink plastic too. The whole production line has a high-degree automation, only need 3-5 operators ,the capacity is: 300kg/h, 500kg/h, 1000kg/h, 2000kg/h, 3000kg/h, the water rate of flakes after cleaning is under 1%. It can save large energy, and guarantee the quality of the flakes at the same time.



    2. Quick Detail:

    The production line includes: belt conveyor, label remover, sorting table, crusher, hot water steamer, screw feeder, high-speed friction washing machine, single/double screw washing machine, centrifugal dehydrator, cyclone hopper and electric cabinet etc.



    3. Description:

    Belt conveyor →Rollin separator 2→Metal separator →Belt conveyer →Crusher →Label Separator →Hot washer 1 →Friction washing machine →Hot washer 2 →High-speed friction washing machine →Rinsing tank →Spray washing →Dewatering machine →Blower dryness system →Storage hopper →Finished product packing



    PVC plastic bottle recycle machine / PET recycling machine high speedPVC plastic bottle recycle machine / PET recycling machine high speed

    4. Applications:

    1. PET mineral water bottles
    2. Cola bottles
    3. PP bottles
    4. PE bottles
    5. ABS barrels
    6. PVC barrels



    5. Specifications:

    Model

    Total power(Kw)

    Capacity(Kg/h)

    Production line length(m)

    PPQX-300

    90-120

    200-300

    25

    PPQX-500

    130-145

    500-600

    30

    PPQX-1000

    150-190

    800-1000

    40

    PPQX-2000

    250-350

    1500-2000

    50

    PPQX-3000

    450-500

    2500-3000

    55



    6. Competitive Advantage:

    The features of this machine: beautiful appearance, low consumption, high capacity and practical and reliable. New rinse device can break with washing, improve the production efficiency and cleaning the materials to achieve the first grade requirements.



    7. Service:



    1. Oversea installation guide.

    2. Oversea test running

    3. Oversea worker training

    4. Technical support

    5. Spare parts supply

    6. Technical operation support

    7. Formula and processing support



    8. Option

    Bottles Recycling Cleaning Production Line uses the features of plastic and water to make bottle sink in the bottom. The following steps are taking off the friction, crushing, washing decontamination and dehydration.



    9. Commercial Terms

    1. Payment: 30% by T/T as advance payment, balance(70%) by T/T before shipment

    2. Lead Time: 60 days after receiving the advance payment

    3. Transportation: container, simple package ( PE film, salver)

    4.Warranty period: From the day of the use of the machine in the buyer’s factory:

       (1) The mechanical Parts: 12 months

       (2) The electrical Parts: 6 months

    5. Installations and Commissioning

       (1) Up to date commissioning has been made before shipment

       (2) Overseas Commissioning and charges

       one or two technicians will be sent to the buyer to guide the installation and commissioning of the              equipment if the customer requests.

       Customers pay the charge of our technicians.

       (1) Round-trip Airplane Ticket

       (2) Charges of transportation, accommodation and communication

       (3) The allowance for the technicians is USD 80 per day for one person.

       (4) An interpreter is needed.

    6. Spare parts:

        Spare parts for one year are needed for the customers, and we suggest that customers should buy the      spare parts. (Fittings list will be provided.)

    7. English manual, Figuration drawing, and footing drawings are provided.
